COMPONENTS

ILLUSTRATION

*1

BLOWER ASSEMBLY

-

-

ILLUSTRATION

*1

NO. 1 DAMPER PLATE

*2

NO. 1 BLOWER DAMPER SERVO SUB-ASSEMBLY

*3

BLOWER MOTOR WITH FAN SUB-ASSEMBLY

*4

AIR FILTER COVER PLATE

*5

CLEAN AIR FILTER

-

-

    Blower Unit

    ..

    Removal

    REMOVAL CAUTION / NOTICE / HINT The necessary procedures (adjustment, calibration, initialization, or registration) that must be performed after parts are removed, installed, or replaced during the blower unit removal/installation are shown below...
