Toyota Yaris: Air Conditioning Pressure Sensor / Components

Air Conditioning Pressure Sensor

..

On-vehicle Inspection

ON-VEHICLE INSPECTION PROCEDURE 1. INSPECT AIR CONDITIONING PRESSURE SENSOR (a) Check the wire harness. (1) Disconnect the A51 air conditioner pressure sensor connector...

Other information:

Toyota Yaris XP210 (2020-2026) Reapir and Service Manual: Components

COMPONENTS ILLUSTRATION *1 INTAKE VALVE GUIDE BUSH *2 EXHAUST VALVE GUIDE BUSH *3 SPARK PLUG TUBE *4 RING PIN *5 STUD BOLT *6 VALVE SPRING RETAINER LOCK *7 NO. 2 STRAIGHT SCREW PLUG *8 NO. 1 STRAIGHT SCREW PLUG *9 INTAKE VALVE SPRING SEAT *10 EXHAUST VALVE SPRING SEAT *11 INTAKE VALVE STEM OIL SEAL *12 EXHAUST VALVE STEM OIL SEAL *13 INTAKE VALVE *14 EXHAUST VALVE *15 INTAKE VALVE COMPRESSION SPRING *16 EXHAUST VALVE COMPRESSION SPRING *17 VALVE SPRING RETAINER - - N*m (kgf*cm, ft...

Toyota Yaris XP210 (2020-2026) Reapir and Service Manual: Inspection

INSPECTION PROCEDURE 1. INSPECT STEERING WHEEL SWITCH HOUSING (a) Check the resistance. (1) Measure the resistance according to the value(s) in the table below. *a Component without harness connected (Steering Wheel Switch Housing) - - Standard Resistance: Light Switch Circuit Tester Connection Condition Specified Condition z6-3 (T) - z4-3 (T) Always Below 1 Ω z6-12 (H) - z4-4 (H) Always Below 1 Ω z6-7 (A) - z4-5 (A) Always Below 1 Ω z6-16 (HU) - z4-6 (HU) Always Below 1 Ω z6-11 (HF) - z4-7 (HF) Always Below 1 Ω z6-8 (TR) - z4-8 (TR) Always Below 1 Ω z6-14 (TL) - z4-9 (TL) Always Below 1 Ω z6-6 (CR) - z4-10 (CR) Always Below 1 Ω z6-13 (BFG) - z4-11 (BFG) Always Below 1 Ω z6-4 (B) - z4-12 (B) Always Below 1 Ω z6-5 (EL) - z4-13 (EL) Always Below 1 Ω Wiper Switch Circuit Tester Connection Condition Specified Condition z5-10 (W_OFF) - z4-24 (W_OFF) Always Below 1 Ω z5-13 (+S) - z4-25 (+S) Always Below 1 Ω z5-11 (+1) - z4-26 (+1) Always Below 1 Ω z5-12 (+2) - z4-27 (+2) Always Below 1 Ω z5-14 (MIST) - z4-28 (MIST) Always Below 1 Ω z5-15 (WF) - z4-31 (WF) Always Below 1 Ω z5-5 (E) - z4-33 (E) Always Below 1 Ω z5-4 (VR) - z4-34 (VR) Always Below 1 Ω If the result is not as specified, replace the steering wheel switch housing...
