Toyota Yaris: Installing Child-Restraint Systems / Installation on rear center seat

Toyota Yaris XP210 (2020-2022) Owner's Manual / Essential Safety Equipment / Child Restraint / Installing Child-Restraint Systems / Installation on rear center seat

The LATCH lower anchors at the center of the rear seat are much further apart than the sets of LATCH lower anchors for child-restraint system installation at other seating positions. Child-restraint systems with rigid LATCH attachments cannot be installed on the center seating position. Some LATCH equipped child-restraint systems can be placed in the center position and will reach the nearest LATCH lower anchors which are 14.2 in. (360 mm) apart. LATCH compatible child-restraint systems (with attachments on belt webbing) can be used at this seating position only if the child-restraint system manufacturer’s instructions state that the child-restraint system can be installed to LATCH lower anchors that are 14.2 in. (360 mm) apart. Do not attach two child-restraint systems to the same LATCH lower anchor. If your child-restraint system has a tether, it must also be used for your child’s optimum safety.

The procedure for installation on the rear outboard seats is the same.

LATCH lower anchor location

Toyota Yaris. Installation on rear center seat

WARNING

Always remove the head restraint and install child-restraint system

Installing a child-restraint system without removing the head restraint is dangerous. The child-restraint system cannot be installed correctly which may result in death or injury to the child in a collision.

4-Door

Toyota Yaris. Installation on rear center seat

5-Door

Toyota Yaris. Installation on rear center seat

Always attach the tether strap to the correct tether anchor position

Attaching the tether strap to the incorrect tether anchor position is dangerous. In a collision, the tether strap could come off and loosen the child-restraint system. If the child-restraint system moves it could result in death or injury to the child.

Always install the head restraint and adjust it to the appropriate position after removing the child-restraint system

Driving with the head restraint removed is dangerous as impact to the occupant’s head cannot be prevented during emergency braking or in a collision, which could result in a serious accident, injury or death. Refer to Head Restraints.

    Installation on rear outboard seats

    First, adjust the front seat to allow clearance between the child-restraint system and the front seat. Make sure the seatback is securely latched by pushing it back until it is fully locked...
